Walk-through Metal Detector with 33zones high sensitivity MCD-900

FOB Reference Price:Get Latest Price
US $850-980 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
MCD
Model Number:
MCD-900
Warranty:
12 Months
Detection zones:
33 zones
Tunnel Size:
200*70*56cm
Net Weight:
54.5kg/set
Dimension size:
222*82*67cm
Sensitivity:
0-199 adjust
Certificates:
CE/ROHS/ISO9001
Quick settings:
5 types
Working environment:
-20℃~70℃,≤95%RH
SupplyAbility
SupplyAbility:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Carton package: door frame:230*72*25cm and operating machine:78*47*28cm total 65kg
Port
shekou,shenzhen
Lead Time :
3-7 days after payment

Walk-through Metal Detector with 33zones high sensitivity MCD-900


Function:

1. Detecting zone: no blind and good uniformity; with LCD display and remote control.

2.Precise positioning: 33 detecting zones,light & sound alarming simultaneously when detect target, two sides’ strip lights showing the specific alarming zone. Thus target will be found in right position.

3.Modular design: modular design, easy installation, easy to repair.

4.Self-diagnosis function: built-in self-diagnostic program, Power-on self-test, error prompt.

5. Microprocessor technology: the control more flexible, all default parameters can be programmed via the control panel, to meet the various requirements of users.

6. Complex circuit design, infrared devices, computer automatic identification, can effectively reduce false alarm and leakage alarm, and can automatically count the number of alarms and numbers of passengers.

7. Having DSP digital signal processing filter systems, have excellent capability in anti-electromagnetic interference  and strong capability in anti-collision , can work normally in crowded situations.

8. Sensitivity adjustment to correspond to 33 zones in six districts, the sensitivity of each detection zone can be independently adjusted from 0-255.

9. Three kinds of preset detection mode, one key switch, one key place; the other with three different alarm volume.

10. Set up for password protection, muti-users display.

Technical parameters:

1, the detection procedures: 255 sensitivity adjustment may satisfy the needs of different occasions.

2. Through rate: more than 60 person per each time / minute.

3. Power Supply:220V AC,50/60Hz.

4. Power consumption: 35W.

5. Working environment:-20℃~70℃,≤95%RH.

6. Tunnel size:200(L)*70(W)*56(H)CM

7. Dimension:   222(L)*82(W)*67(H)CM

8. Package size:Main Body:230*72*25CM(2pcs/CTN)

                Host machine:78*47*28CM(1pc/CTN)

9. N.W.:54.5kg/set  G.W.:65kg/set

10.Quick settings: 5 different application locations

11.Pass mode:person account 3 types in&out,in or out only










Our Certificate:


Deliver time : 5-10 days after confirming order, details delivery date should be decided by production season and order quantities



Service: Warranty 1 year, there are professional staff to help deal the issue.



The package pictures: package with the carton case














Contact us:

Tel:+86 755 84676682 ext.805   | Cell:  +86 152 7468 6013 | Skype :+8615274686013  | Wechat: 15274686013



Email: sales4@gdmcd.com ; XvilWang@163.com  |  Website: www.mcd168.com ;  www.doorframemetaldetector.com



SHENZHEN MCD ELECTRONICS CO.,LTD

2F, NO.1 BLDG, Chunhu Industrial Zone, E 'gongling Village, Pinghu Town, Longgang District, Shenzhen City, P.R.C.
