MCD-6550 X-ray Vision System with excellent sensitivity luggage scanner

FOB Reference Price:Get Latest Price
US $8,848-13,056 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
MCD
Model Number:
MCD-6550
Tunnel Size::
650(W)*500(H)mm
Conveyor Speed::
0.22m/s
Conveyor Max Load::
170kg
Penetration::
34mm Steel
Film Safety::
Guarantee ISO1600 Film
Generate angle::
80 degree
Power Consumption::
1.0 KW (max), 0.7KW(working)
Operation Power::
220VAC(±10%)50±3Hz
Noise::
<58db
Supply Ability
Supply Ability:
80 Set/Sets per Week X-ray Vision System
Packaging & Delivery
Packaging Details
standard package
Port
shenzhen
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 3 To be negotiated

MCD-6550 X-ray Vision System with excellent sensitivity Specification:

  • Tunnel Size: 650(W)*500(H)mm
  • Conveyor Speed: 0.22m/s
  • Conveyor Max Load: 170kg
  • Dose per Inspection <1.4Gy/h
  • Resolution < 0.0787mm Copper Wire
  • Spatial resolution Level: dia1.0mm,
  • Vertical: dia1.0mm
  • Penetrate resolution: Dia 0.254mm
  • Penetration: 34mm Steel
  • Film Safety: Guarantee ISO1600 Film
  • X-ray Leakage: <0.05 μGy/h (at a distance of 5cm From external housing

X-ray Generator

  • Generate direct: Upward
  • Generate anger: 80 degree
  • Anode Voltage: 100~160Kv
  • Anode power: 0.4 to 1.2mA
  • Cooling / Duty Cycle: Oil Cooling /100%

Image System

  • X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
  • Monitor: High Resolution Color, LCD Accord, 17 inch
  • Image Processing: Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.
  • Image Grey Level: 4096
  • Image Max Resolution: 1024 * 1280 pixel
  • Image Processing: 24bit for processing real time
  • Image storage: Storage 60000 pictures in real time
  • Zones & Zoom: 1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation
  • Multi-energetic distinguish objects : organic objects in orange, inorganic objects in blue, mixture in green
  • High-energy/low energy : switch from high energy to low energy
  • Assist to detect drug and explosive powder

Installation Data

  • Operation temperature/Humidity: 0°C-45°C/20%-95%(non-condensing)
  • Storage Temperature/Humidity: -20°C-60°C/20%-95%(non-condensing)
  • Operation Power: 220VAC(±10%)50±3Hz
  • Power Consumption: 1.0 KW (max), 0.7KW(working)
  • Noise: <58db



Features

  • Sound and light alarms
  • Network Interface: Can connect local area networks, multiple terminals can check luggages at the same time.
  • Safer-ray: Ray fired automatic control, to avoid misusing launching.
  • Simple mouse control: can directly control the equipment without the keyboard and the working table.
  • One shutdown control button: You just need to rotate the key and the equipment will automatic power off safely, no need for complex multi-step operation, more convenient and simpler.
  • Eagle Eye: Current region can be reviewed conviently in enlarged status.
  • Fault self-diagnosis: Automatically determine the failure and give prompt information, easy to maintain.

MCD-6550



Application:

         Used in the factory testing of security products and business units such as: electronic factories, shoe factories, toy factories, courts, railway stations, and event bag, line security management package






Our company:



.jpg

Certification:



.jpg



If you have any questions, pls feel free to contact us, you’ll be replied prompt!
