MCD-8065 Used In Airport Subway Cargo Security Detector Cargo Inspection X-ray machine

FOB Reference Price:Get Latest Price
US $12,500-17,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
MCD
Model Number:
MCD-8065
Detection mode:
x-ray top shine detecting
conveyor max load:
220kg
conveyor speed:
0.2m/s
steel penetration:
40 mm metal line
power wastage:
1kw(max)
warranty:
2 year
Tunnel Size:
800(W)*650(H)MM
Maximum leakage radiation:
<0.05uGy/h
Noise:
<58 dB
System Power:
220AVC/50Hz
Supply Ability
Supply Ability:
300 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden case package
Port
Shenzhen
Lead Time :
within 5 days after received payment

MCD-8065 Used In Airport Subway Cargo Security Detector Cargo Inspection X-ray machine



Feature:



Sound and light alarms



Network Interface: Can connect local area networks, multiple terminals can check luggage’s at the same time



Safer-ray: Ray fired automatic control, to avoid misusing launching.



One shutdown control button: You just need to rotate the key and the equipment will automatic power off safely, no need for complex multi-step operation, more convenient and simpler.



Eagle Eye: Current region can be reviewed convent in enlarged status.



Fault self-diagnosis: Automatically determine the failure and give prompt information, easy to maintain.





Parameters



Tunnel Size: 800 (wide) × 650 (high) mm

Conveyor speed: 0.2 m / s.

Conveyor Max load: 200kg belt

Single inspection dosage: <1.5μGy

Wire Resolution: 0.101mm metal line

Steel Penetration: 34mm armor plate

Film safety: For ISO1600

Maximum leakage radiation: <0.o5µGy/h





X-ray generator



Orientation: Vertically Upward

Tube current: 0.4 ~ 0.7mA (adjustable)

Anode voltage: 100 ~ 160 kV (adjustable)

Angle: 60 °

Generator Cooling/working periods; Sealed oil with forced air/100%



Operation environment



Storage temperature:-20 °C to 60 °C

Operating Temperature: 0 °C to 45 °C

System power: 220VAC (± 10%) 50 ± 3Hz

Power wastage: 1.0KW (Maximum)

Noise : <65DB









Feature and Application



X-ray penetrate inspection, the object can be found within the metal structure, can display

the naked eye can not see where the liquid is also very obvious object display.

Used in the factory testing of security products and business units such as: electronic factories,

shoe factories, toy factories, courts, railway stations, and event bag, line security management package
